  • Product Details

LONGT LIGHTING GROUP has been investing a lot in product development and has gained positive results. The use of in Hot Selling 250w Flexible Solar Cells Solar Panel For City Square manufacturing has allowed us for more efficient use of resources and personnel.The product is highly recognized in the application field(s) of Solar Panels. Research and development are the pillars on which the future of our company rests. LONGT LIGHTING GROUP will put more emphasis on improving our R&D strength in the future for developing more creative and competitive new products.

Brand NameLONGT, OEMModel NumberLSP-10-250
Place of OriginJiangsu, ChinaCell size/
TypePERCPanel Dimensions1640*992*50mm
Panel Efficiency15.36%CertificateCE
Warranty3 years, 3 yearsProduct name250w flexible solar cells solar panel for city square
Size1640*992*50mmCell Types156*156mm
Weight23.5kgMax Load5400 Pascals
Maximum System Voltage1000VPower Tolerance0 to +5W
ApplicationCity square, Station, Wharf, Warehouse, Highway, Stadium, Overpass.


Model Type
LSP-10-240
LSP-10-245
LSP-10-250
LSP-10-255
LSP-10-260
LSP-12-310
Peak Power(Pmax)
240w
245w
250w
255w
260w
310w
Module Efficiency
14.75%
15.05%
15.36%
15.67%
15.98%
15.97%
Maximum Power Voltage(Vmp)
31.4v
31.7v
31.9v
32.2v
32.4v
39.2v
Maximum Power Current(Imp)
7.63A
7.73A
7.83A
7.93A
8.02A
7.91A
Open Circuit Voltage(Voc) Short
37.9v
38.1v
38.4v
38.6v
38.9v
47.0v
Circuit Current(lsc)
8.57A
8.63A
8.69A
8.74A
8.80A
8.63A

Solar panel

Advantage:
High efficiency and transmission rate, low iron tempered glass,Manufacturing with IEC61215 standard
Types of solar panel:
Mono crystalline silicon & Poly crystalline silicon.

The features

The high efficiency solar PV module adopts the world’s highest efficiency cell with efficiency up to 23%, and efficiency of the
module is 25-30% higher than the traditional ones, this cell’s positive pole and the negative pole are on the same side, the
cell’s front side can absorb maximum sunlight, so that it can get the maximum power.
