After a long period of exploration,LONGT LIGHTING GROUP has launched China 12v 200w Photovoltaic Solar Cell Panel. At LONGT LIGHTING GROUP, it is our goal to provide the highest quality products and superior service to our customers, both being our top priority. Under the leadership of our company's board of directors, LONGT LIGHTING GROUP have constantly upgraded our technologies and introduced high-end machines to continuously drive the market trend and improve product quality so as to satisfy every customer. Our aim is to become one of the most trustworthy enterprises in the market.

Brand NameLONGT, OEMModel NumberLSP-8-200
Place of OriginJiangsu, ChinaCell size/
TypePERCPanel Dimensions1580*808*45mm
Panel Efficiency15.66%CertificateCE
Warranty3 years, 3 yearsProduct namechina 12v 200w photovoltaic solar cell panel
Size1580*808*45mmCell Types125*125mm
Weight15.5kgMax Load5400 Pascals
Maximum System Voltage1000VPower Tolerance0 to +5W
ApplicationCity square, Station, Wharf, Warehouse, Highway, Stadium, Overpass.


Model Type
LSP-8-185
LSP-8-190
LSP-8-195
LSP-8-200
LSP-12-305
LSP-12-310
Peak Power(Pmax)
185w
190w
195w
200w
305w
310w
Module Efficiency
14.49%
14.88%
15.27%
15.66%
15.71%
15.97%
Maximum Power Voltage(Vmp)
37.4v
37.7v
38.0v
38.3v
38.9v
39.2v
Maximum Power Current(Imp)
4.94A
5.04A
5.13A
5.22A
7.84A
7.91A
Open Circuit Voltage(Voc) Short
45.1v
45.4v
45.7v
46.0v
46.7v
47.0v
Circuit Current(lsc)
5.58A
5.65A
5.72A
5.79A
8.60A
8.63A

Solar panel

Advantage:
High efficiency and transmission rate, low iron tempered glass,Manufacturing with IEC61215 standard
Types of solar panel:
Mono crystalline silicon & Poly crystalline silicon.

The features

The high efficiency solar PV module adopts the world’s highest efficiency cell with efficiency up to 23%, and efficiency of the
module is 25-30% higher than the traditional ones, this cell’s positive pole and the negative pole are on the same side, the
cell’s front side can absorb maximum sunlight, so that it can get the maximum power.
