LED Street Light (AC Powered)
VR
  • Products Details

LONGT LIGHTING GROUP In-depth analysis of the actual needs of target customers, combined with its own advantages resources, successfully developed Longt 30w Professional Outdoor Led Solar Street Light With Motion Sensor. Solar Street Lights Guided by market forces,LONGT LIGHTING GROUP will use a comprehensive range of measures to enhance our strength. For example, we will invest heavily in the R&D project and keep developing new products so as to lead the market trend.

Place of OriginJiangsu, ChinaBrand NameLONGT
Model NumberLED20WApplicationROAD
Color Temperature(CCT)5000K (Daylight)IP RatingIP66
Beam Angle(°)120CRI (Ra>)75
Input Voltage(V)DC 12VLamp Luminous Efficiency(lm/w)120
Lamp Luminous Flux(lm)9600Warranty(Year)5-Year
Working Temperature(℃)-10 - 45Color Rendering Index(Ra)70
CertificationCQC, CCC, cePower SupplyBattery
Light SourceLEDSupport DimmerYes
Lighting solutions serviceLighting and circuitry design, DIALux evo layout, auto CAD layoutLifespan (hours)50000
Working Time (hours)50000Product Weight(kg)9.5
Product name20w Solar street lightCertificateCE/RoHs
Solar Panel18VCharge time6 hours
Load Power (W)60Output Voltage (V)12V

Products Description
Light source
30w LED Street Light, Bridgelux/Philips chip, 50000 hours life span, ≥9600 Lumens, 5 years warranty
Solar Panel
Polysilicon PV modular, 2pcs of 45w, 17%-19% convert rate, 10 years warranty
Storage Battery
Deep cycle gel battery,Lithium battery 12.8V 30Ah capacitor, 3 years warranty
Controller
Intelligent controller, light control, time control, with overcharge protection, with remote control to turn on and off.
Light post
Material: Q235, Height: 6m, thickness: 3mm, finishing: hot dip galvanized and power coated with RAL color, with base plate and
anchor bolts
Cable
2*2.5mm² copper cable

LED lamp

* Lamp Body: Die-Casting Aluminum. Corrosion Resistant
* Application with Polyester Substance in its Surface.
* Implement of Reflect: Made of High Purity Aluminum.
* Cover: High Strength and High Transparent Toughened Glass
* Fastener Bolt and Screws: Stainless Steel
* Arm Diameter: 48 - 60mm
* IP65

Pole

* Finish: Black; hot dip-galvanized (HDG) only; HDG plus powder coated
* Galvanization standard: ASTMA123/EN ISO1461
* Welding: AWS D 1.1/BS EN 1011-1,BS EN 1011-2
* Design: We have our standard pole with our design, OEM and ODM is also acceptable
* Package: Standard seaworthy
* Delivery time: with two weeks after confirm the order
* Thickness: 1mm to 4mm

Solar panel

* Monocrystalline Solar panel , efficiency of more than 18.5%
* Polycrystalline solar panel, efficiency of more than 17.8%
* A GRADE high efficient solar panel
* Hydrophobic layer with higher light absorption and minimal surface dust
* 10 years warranty for solar panels

Battery

* Low-internal resistance clapboard, low internal resistance, good battery capacity Self-discharging rate less than 3% every month
* Gassing rate of gelled batteries is only 5% of ordinary sealed batteries.
* The lifespan is greater than 1000 times at 25C°
